Products Descriptions
โย Product name:ย Aluzinc Steel Coil
โย Standards: AISI, ASTM, BS, DIN, GB, JIS
โย Place of origin: Tianjin, China (Mainland)
โย Brand name: Runfei
โย Payment terms: L/C, T/T (30% deposit)
โย Certifications: ISO 9001, SGS, RoHS Directive-compliant
โย Packing details: Standard seaworthy packing, horizontal type and vertical type are all available
Our Advantages
โย We can provide factory price with trading company services
โย We control production quality very strictly to keep none compensation
โย We guarantee 24 hours response and 48 hours solution providing service
โย We accept small order quantity before formal cooperation
โย We offer good quality with reasonable price, faster delivery with better payment terms
โย We have professional teams and the factory
โย It’s very important for a company to be honest in the process of trading and so do we
Similar to galvanized steel, Galvalume is produced by a hot-dip process. Instead of 100% zinc, the dip is 55% aluminum, 43.5% zinc and 1.5% silicon. Galvalume Steel Coil have excellent performance, possessing ideal comprehensive properties of corrosion resistance, formation and coating.
Galvalume Steel (also called Aluzinc Steel) are mainly used in building, automobiles, metallurgy, electric equipment and more.
โ Building โ roof, door, window, roller shutter door and suspended skeleton
โย Automobiles โ vehicle shell, chassis, door, trunk lid, oil tank, and fender
โย Metallurgy โ steel sash blank and color coated substrate
โย Electric equipment โ refrigerator base and shell, freezer, and kitchen equipment
As a leading galvalume steel coil manufacturer, Runfei Steel adheres to strict quality standards to produce our galvalume steel coils/sheets. We guarantee our products meet our customer’s requirement.
1. Color Coated Steel Coil is coated with organic layer, which provides higher anti-corrosion property and a longer lifespan than that of galvanized steel sheets.
2. The base metals for Color Coated Steel Coil consist of cold rolled, HDG electro-galvanized and hot-dip Aluzinc coated steel. The finish coats of Color Coated Steel Coil can be classified into groups as follows: polyester, silicon modified polyesters, polyvinyl Dene fluoride, high-durability polyester, etc.
3. The production process has evolved from one-coating-and-one-baking to double-coating-and-double-baking, and even three-coating-and-three-baking.
4. The color of the Color Coated Steel Coil has a very wide selection, like orange, cream-colored, dark sky blue, sea blue, bright red, brick red, ivory white, porcelain blue, etc.
5. The Color Coated Steel Coil can also be classified into groups by their surface textures, namely regular prepainted sheets, embossed sheets and printed sheets.
Grade SPCC SGCC SGHC Q195 Q235 Q215 DX51D
Thickness 0.12-1.4mm
Width 600-1250mm(usual size:762mm,914mm,1000mm,1200mm,1219mm,1220mm,1250mm,)
Base metal Galvanized steel coils
Zinc coating 60-275gsm
Coil Internal Diameter 508 mm/610mm
Surface treatment Bright and clean, smooth and flat
Coating structure Top+ Prime/Back, PE/EPOXY; 20- 25 microns/5-7 microns
Lifespan 10-15 years, very strong corrosion resistance it wouldn’t fade.
Tolerance Thickness:+/-0.05 mm, width: +5/-2 mm; Total quantity: +/-10%,Zinc coating: +/-10%
Tensile Strength>300mpa
Yield Strength 370-380mpa
Machine features Suitable for molding and join-up shaping, welding processes
Coating thicknessTop: 17-25um back:5-8um
Color options Ral number or as per your request
Type Steel coil/Steel sheets or plates/Corrugated steel sheets or plates
Packing Standard seaworthy export packing: 3 layers of packing, inside is craft paper, water plastic film is in the middle and outside GI steel sheet to be covered by steel strips with lock, with inner
